Lindapter Type AMD Decking Fixing

Lindapter
  • Brand: Lindapter
From £212.00 ex. VAT per 100From £254.40 inc. VAT per 100

Description

High quality, cost effective decking fixing designed for AMDECK 60 and AMDECK 80 profiles manufactured by AMDECK (formerly Anglian Metal Deck)

Overview

The Type AMD is a high quality, cost effective decking fixing designed to fit inside the dovetail re-entrant channel of the AMDECK 60 and AMDECK 80 composite decking profiles manufactured by AMDECK (formerly Anglian Metal Deck). The fixing comes in two parts (locking plate and wedge) and provides a zero-impact method of connection that avoids delamination and damage to the concrete deck. After the concrete deck has been poured and has reached full strength the Type AMD is installed with an appropriate threaded rod from where building services can be easily and quickly suspended.

Features & Benefits

  • Quick and easy to install.
  • Adjustable for precise alignment.
  • Zero impact connection to roof deck.
  • No damage to the decking.
  • No requirement for specialist labour / tools.

Approvals

  • CE Marked
  • Manufactured to ISO9001 and ISO14001

Properties

  • Locking plate is a pre-galvanised strip
  • Wedge is manufactured from malleable iron with a bright zinc plated finish
  • Reaction to fire: A1 (Steel)
  • Durability and corrosion protection:
Corrosivity Class Galvanised Steel Electroplated Steel
C1 More than 50 years More than 20 years
C2 More than 50 years More than 5 years
C3 More than 20 years Not Suitable

Product Options

Part CodeNameRod min 4.6Tensile / 1 Rod kNTightening Torque NmStockPrice (per 100)Qty
AMD10Lindapter M10 Type AMD Decking FixingM10110

Live Stock Unavailable

In Stock

Available to Order

£212.00 ex. VAT £254.40 inc. VAT
